SKU
M5-CB08
M5-CB08 Impinger Cold Box (M202)
The M5-CB08 Impinger Cold Box is designed to hold 6 impingers comfortably and may hold up to 12 impingers. The impinger box insulation is waterproof to eliminate breakdown and the corners are fully welded to accommodate the extra weight of ice and water. When purchased with the M5-CB08-LIN Liner the box becomes a dual compartment cold box for Method 202 apparatus.
Features
- Holds 8 to 12 Impingers
- Stainless Steel Handle With Centering Loop
- Stainless Steel Spring Loaded Locks for Secure Attachment to Filter Box
- Slide Block With Thumbscrew for Outlet Adapter or Strain Relief Bracket
- Waterproof Insulation
- Built-in Drain With Gasket
- Welded Construction
Specifications
- 14-1/2"L x 9-1/2"W x 13"H (OD)
- Weight: 10 lb.
- Closed Cell Foam Insulation
- Stainless Steel Handle and Mounting Slide Brackets
- Mounting Block With Thumbscrew
- Spring Loaded Locks for Secure Attachment to Filter Box
